The DCC NeoFlex F‑51350+ Pro is a fully integrated, high‑speed commercial direct‑to‑film (DTF) system that combines printer, automated powder dispenser, shaker, curing dryer, and dual HEPA + carbon filtration into one steel‑framed unit
Core Design & Integration
Unlike “patchwork” setups made from separate machines, the F‑51350+ Pro is engineered as a single ecosystem:
-
Printer + Powder System + Dryer + Filtration in one frame, eliminating registration drift and alignment issues between separate units
-
Solid core steel construction for stability and head alignment
-
Dual HEPA + carbon filtration built in, removing the need for a separate fume extractor
Printing & Performance
-
6 Epson I3200‑A1 printheads: 3 for CMYK, 3 for white ink
-
Production speed: ~16.5 m²/hr (≈177 sq ft/hr)
-
Resolution: up to 720 × 2400 DPI in 8‑pass mode
-
SmartRIP software with auto‑nesting, color profiling, and print queue management
-
Precision film handling with push‑button pincher, vacuum adjustment, and pivot roller
Key Features
-
Automated powdering: precision dispenser and shaker for even adhesive coverage
-
Smart ink management: 1.7 L tanks, auto white ink recirculation, low‑ink alerts
-
Preventive maintenance: automatic capping/wiping to reduce downtime
-
Modular upgrades: add heads/colors without replacing the whole machine
Flexible Production
The F‑51350+ Pro supports both traditional powdered DTF and powderless DTF workflows:
-
Powdered DTF: proven durability, adhesive powder applied after printing.
-
Powderless DTF: specially formulated inks create adhesion without loose powder, offering softer hand and cleaner workspace.
This flexibility lets shops choose the process best suited to garment type and customer needs
Industry Recognition
The model won the 2026 PRINTING United Alliance Pinnacle Awards in both black‑shirt and white‑shirt DTF output categories, recognized for performance in challenging dark‑garment underbase and white‑ink handling
